Firemiser Insulated Rolling Fire Door

Name: Firemiser Insulated Rolling Fire Door
Brand: Cookson Door

Fire Doors

Model Number: ERD20 and ERD21

INSULATED ROLLING FIRE DOOR

Our Firemiser rolling door offers all of the life safety benefits of a rolling fire door along with the energy efficiency and sound reduction of an insulated rolling door.

This insulated fire door will close in the event of a fire, acting as a physical barrier to prevent smoke and flames from spreading throughout the building. By keeping the incident isolated, both lives and property are protected.

The insulation used in this door is made of mineral wool, which helps to decrease sound transmission – with an R value of 5.3 and a U Value of .189 based on the ASHRAE Handbook of Fundamentals. The mineral wool also minimizes thermal transfer, which helps to keep the climate controlled air inside and the uncontrolled temperature outside.

A Firemiser insulated fire door is ideal for an application that is on the exterior of a building but may be expanded in the future or an area that requires a fire door but also needs the sound deadening benefit of an insulated door.

Our insulated roll up fire door is UL listed, Factory Mutual Approved and listed with the California Office of the State Fire Marshall. It is listed with a protection ratings of 45 minutes, 90 minutes, 3 and 4 hours.

The SmokeShield® seal package is available on model number ERD21. This option is added if you are required to conform to UL 1784. This seal package is an additional barrier that will eliminate the migration of smoke through the building.

Technical Detail Information:
Firemiser Brochure & Details Sheet Generate a Custom Drawing Architectural Assistance

Mounting Options

Insulated fire doors can be installed face of wall or between jambs on an interior or exterior wall. Acceptable wall types include masonry, structural steel jambs and drywall construction with structural steel or wood studs.

Materials and Finishes

Firemiser curtains are available in:

Steel

Interior slat 24 gauge / Exterior slat 24 gauge

Interior slat 22 gauge / Exterior slat 24 gauge

Interior Slat 20 gauge / Exterior slat 24 gauge

Interior slat 18 gauge / Exterior slat 24 gauge

Stainless Steel

Interior slat 22 gauge / Exterior slat 22 gauge

Click here for additional material and finishes options and information.

Finish and gauge availability may vary. Contact us with any questions.

Sizes

A standard UL labeled fire door is available up to 13.5' wide by 12' high.
An oversized UL labeled fire door is available up to 60' wide or 40' high or 1,200 sq. ft.

For openings that fall outside of the standard construction, please contact us

Unique Design Solutions

Sloping or Irregular Openings

Our special bottom bar designs can address these conditions.

Learn More

Aesthetics

Omni Powder Coat Finish

Our environmentally friendly Omni Powder Coat helps you to match your rolling steel door to select Clopay sectional doors.

Omni Powder Coat is available in:

Commercial Tan
Commercial Gray
Charcoal
Standard White
Chocolate Brown
Black

Learn More

SpectraShield™ Powder Coat Finish

Polyester finish in more than 180 colors for durability, aesthetics, superior finish life and cost effectiveness.

Learn More

Hood and Operator Covers

Metal cover to protect the coil or operator from exterior weather, debris or to meet OSHA or UL 325 safety requirements.

Learn More

Finishes Colors & Options

Finishes Colors and Options

Finishes Colors & Options Sheet
AtmoShield® Color Options
Powder Coat RAL Color Chart

Safety and Protection

Sensing Edge - Entrapment Protection Device

Designed with a flexible black rubber TPE material, our new sensing edge has two fins that conform to variations in the floor on both the interior and exterior of your door or grille ensuring a secure seal without requiring you to overset the bottom door limit. The sensing edge is easy to clean and remains free from rust and dirt stains, maintaining a fresh uniform appearance. With flexible 1" sealing fins, our sensing edges provide maximum protection while withstanding the elements.

Edges are tested and listed to UL 10B as a component of the rolling steel fire door assembly.

To determine the best entrapment device for your application, check out our Entrapment Device Protection Overview document.

Entrapment Protection Devices

Entrapment protection devices ensure that a motorized door or grille will not close on an object. If an object enters path of closure, the entrapment protection device will stop the door or grille from closing and return it to the fully open position.

Learn More

Guide-Mounted Interlocks

An electrical cutout switch to prevent motor operation if locking device is not first disengaged.

Learn More

Rolling Door Protector (RDP)

The RDP eliminates costly fork truck damage to coiling doors by creating a physical barrier at the top of the door that absorbs impacts.

Learn More

Static Wind Load

Can be configured to withstand the full range of specific wind load requirements including missile impact ratings.

Learn More

Performance Upgrades

High Cycle Springs

Heavy duty springs manufactured to withstand cycles of 100,000.

Learn More

Seismic Performance Validation

We can provide project specific seismic calculations for all coiling doors that are mounted Face of Wall to steel or masonry. Seismic performance validation is per ASCE 7-05.

Learn More

Fire Specific Options

Battery Back Up Devices

Available for motor, chain and crank operators, these devices prevent fire doors from closing from a power failure.

Learn More

Firefly & Firefly BB Release Device

Optional device that ties in to a building alarm system and closes a Simple-Test fire door upon alarm activation, rather than by melting its fusible link.

Learn More

SmokeShield® Seal Package

Often required by local building codes, our smoke seal adds smoke and draft control.

Learn More

Testing Stations

Safely and conveniently test and reset the functionality of the fire door at floor level. May be flush or recess mounted.

Learn More

SmartSync Wireless Safety Edge Kit

SmartSync™ Wireless Safety Edge Kit & Wireless Remote Control

The Smartsync™ Safety Edge Kit is an upgrade for our existing Safety Edge. This allows for wireless communication between the transmitter and the receiver, eliminating the coiling cord in the door opening. Learn more.

The Smartsync™ Wireless Remote allows wireless control of your door or grille. This heavy-duty remote comes equipped with an anti-shock design and is compatible with most motor-operated doors, grilles or counter doors.*
*Not compatible with NEMA 7/9 operators
Learn more.

Technical Data Sheets

Firemiser Insulated Rolling Fire Door Technical Sheet

Specification Sheets

Firemiser Insulated Rolling Fire Door Specification

BIM Objects

Drawing Generator

Need to see clearances and mounting details? Enter your opening dimensions into our Drawing Generator, and get custom generated drawings of your door with all the details.
